SPECIFICATIONS

General Features

Total Power: 1000W

Disc Capacity: 1

Deck Type: Tray

Number of Channel: 5.1

Playable Disc Type

3D Blu-ray: Yes

Blu-ray Video: Yes

DVD-Video/DVD±R/DVD±RW: Yes

CD DA/CD-R/CD-RW: Yes

VCD 1.1: Yes

Audio Feature

Dolby Digital: Yes

Dolby Pro Logic II: Yes

Dolby Digital Plus: Yes

Dolby True HD: Yes

DTS: Yes

DTS 96/24: Yes

DTS HD: Yes

DTS Neo:Fusion: Yes

3D Sound Plus: Yes

Vertical Surround: No

Smart Volume: Yes

MP3 Enhancer: Yes

Power Bass: Yes

Simple Speaker Setup: Yes

Virtual Surround (Virtual 7.1 / Virtual 5.1): Yes (virtual 7.1)

User EQ: Yes

Local EQ: No

Football Mode: Yes

Auto Sound Calibration (ASC): No

Number of Sound Modes (DSP): 9

Video Feature

BD Wise: 3.0

BD Profile: 5.0

4K upscaler: No

BD Live: Yes

Video Up-Scale (DVD): Yes

Connectivity

Anynet+ (HDMI-CEC): es

AllShare (DLNA): Yes

AllShare Play: Contents Sharing

USB Host 2.0: Yes

Wireless LAN: Ready

Wi-Fi Direct: No

Wireless Speaker Module included: No

Bluetooth: Yes

ARC (Audio Return Channel): Yes

HDMI Out: Yes

Number of HDMI Input: 1

Number of Audio Input: 1

Number of Optical Input: 1

Number of coaxial Input: 0

Headphone Jack: No

Tuner

FM: Yes

RDS: No

AM: No

Special Feature

Dual Core: Yes

Crystal Amplifier Plus: Yes

Valve Amp: No

GaN Amp: No

CPID Unit: No

CD Ripping: Yes

TV Sound On: Yes

Web Browser: Yes

Movies & TV Shows: Yes

Network Service: Smart Hub (Apps & Service)

Speaker

Type (Tallboy/Satellite/Swivel): 4 Tall-boy

Sub Woofer: Passive

Front: Full Range

Center: Full Range

Surround: Full Range

Dimension

Product Dimension (WxHxD): 430 x 55 x 250mm

Spk (Sub Woofer) Net Dimension (WxHxD): 155 x 350 x 285mm

Spk (Front) Net Dimension (WxHxD): 95 x 1100 x 75mm

Spk (Center) Net Dimension (WxHxD): 227 x 95 x 75mm

Spk (Surround) Net Dimension (WxHxD): 95 x 1100 x 75mm

Gross Dimension (WxHxD): One Packing: 876 x 357 x 416mm

Power

Stand-by Power Consumption: 0.5

Operating Power Consumption: 72.5

Free Voltage: No
